Amazonas W-Flow Swim Spa

  • Sale
  • Regular price £24,199.00
Tax included. Shipping calculated at checkout.


The Amazonas W-Flow Swim Spa is an energy efficient swim spa with an advanced swim system that provides an enhanced swimming experience and a perfect water flow. It is designed for swimming, fitness, and relaxation, with a focus on energy efficiency and a sophisticated filtering system.

The Amazonas Swim Spa - Exceptional solutions, available with semi cabinet design. We have now designed two sitting places, so you can use professional swimming and unique massage. A side-mounted filter housing is now placed at the end of the swimming area so that the floating area is wider. Versatile use, a perfect combination for swimming and children’s paddling.
NEW W-Flow Swim Spa System
In a traditional swim spa, the user has to switch on/off the pumps manually for finding the proper water flow which fits their fitness level. The Amazonas swim spa is equipped with brand new swim software. Combining this and the new W-flow Swim spa system the Amazonas became a professional training appliance.
The user can choose six-speed levels from the slowest, most comfortable „floating” to the hardest exercise. Similarly to a modern treadmill, you can predefine the swimming speeds one after another, so you can insert slower stages between the swimming sprints.
The flow rate can be adjusted 0.4-2.5 km / h.

    • It can deliver twice as much water against traditional types of swim spas, approx 180 m3/h.

    • The width of the water flow is only 50-60 cm.

    • The difference between water flow directions and the centerline of the spa is 0° therefore swimming is perfectly balanced.

    • Mechanical elements are separated from the hydro-space, so any mechanical repairs can be done without sluicing the water.

    • The heat pump connection in the swim spa is fixed and equipped within. Grid system - consequently, the heating cost can be reduced to one-third of the electrical heating making this swim spa more economical than most.

    • Both the massage and the swim half can be separately controlled with the in.touch 2 application.

    • Self-drain function - the swim half can be drained by the circulation pump: 10 m3 in 33 mins.
Learn more about the lates swim spa innovation from Wellis!

Thanks to the several training sessions this swim spa is suitable for professional swimmers and beginners too.
You can experience endless swimming with this new fitness machine. It’s like having your own coach to watch over you. The training session can be customised by setting flow intensities, durations, and colour indicators. Before choosing a training drill, we recommend adjusting the parameters. Touch the settings icon on the right icon wheel. From there, you can access 6 different parameters.
A swimming workout executed at a constant intensity for the entire set duration.
A swimming workout executed at high and low-intensity intervals of equal step time.
A series of equal steps at random intensities.
A swimming workout executed at two successive steps at high intensity for one step at low intensity.
A pyramid program where the intensity will progressively increase until a maximum intensity level is reached. It will then decrease progressively to end at low intensity.
You can create custom workouts.
Dimensions 5500 × 2350 × 1500 mm
Net weight (kg) / Water volume (l) 1 150 kg / 8 036 l
Frame Stainless steel
Side cover HorizontSide™ or semi-inground
Reinforcement Fiberglass reinforced
Insulation Polyfoam (2 cm)
Drains D50 ball valve

1×60A 230V/50Hz opt.

1x35A 230V/50Hz min.

Control box Gecko (IN.YE-8)
Control panel SmartTouch
Total number of jets 27 pcs
Laminar fountain jets 6 pcs
Heater 3 kW
Pumps (hydro massage) 1 pc 3 HP single speed + Circ. pump
Pumps (swim spa) 3 x 3 HP 2 speed
Filtration 4 pcs antibacterial paper filters
Water sanitization UV-C lamp
LED lights 25 pcs LED + illuminated control valves
Headrests 2 pcs
Sound system AquaSoul™ Pro 4.1
SmartPhone app - wifi connection Yes
Thermo cover Yes
Swimming stick Yes
Heat exchanger preparation Yes
  The Amazonas swim spa is available with a semi-cabinet - what makes it possible to sink the spa halfway only in the ground without any concrete preparation.
*In case of minimum power connection, the hot tub pump(s) and heating unit cannot be operated simultaneously.
